Virtus M1 Reference Line

Vacuum Mono Tube Power Amplifier

Pure Class A Technology

  • Solid aluminium chassis – leads to the overall robustness and eliminates the vibrations
  • Supersymmetric design – eliminates interfering signals
  • Extremely low harmonic distortion – one of the best ever seen in vacuum tube amps
  • The transformer core is vacuum impregnated, and the entire transformer is encapsulated in a special anti-vibration compound
  • The filtration capacity is 3.900mF/550V. A choke, that is placed under welded cover, has been used to eliminate anode voltage ripple
  • The output permalloy transformers specially designed for the power amplifier.
  • Only high-quality polypropylene capacitors are used in the signal path
  • The conductors on the signal paths consist of slow drawn oxygen-free copper, which is coated with pure silver.
  • SRP 14.200,00 €
Technical Specification
Gain     24 dB / 4 Ohm
Output Power  – ultra linear mode 1 x 110W / 8 Ohm – ultra linear  (THD < 3%)
Output Power  – triode mode 1 x 55W / 4,8 Ohm – triode (THD < 3%)
Frequency range 10 – 50.000 Hz ±0,5dB / 5 W
Input Impedance 200 kOhm
Inputs  1 x XLR
Harmonic Distortion  <0,05% (1 kHz, 5W / 8Ohm - ultra linear)
Harmonic Distortion  <0,005% (1 kHz, 1W / 8Ohm -ultra linear)
Siganl-to-noise-ratio >103 dB (20Hz-80kHz)
Tube complement  4 x KT150, 2x ECC82, 1x 12AX7
Power    230 V / 50-60 Hz
Dimensions (w x h x d) 450 x 190 x 465 mm
Weight (net)  40 kg
Expected  availability 1st Quarter 2022
