Asterion V2 Premium Line

Tube Phono Preamplifier

  • an all-tube turntable preamplifier for both MM and MC phono cartridges
  • nine tubes, one vacuum tube out of them used to rectify anode voltage
  • wiring circuitry without any global feedback
  • PCB’s utilize our premium CMT ™ technology
  • precise selection and matching of the tubes that have above-average parameters
  • vacuum-impregnated transformer core
  • transformer potted in a special anti-vibration compound and placed in the massive welded cover
  • the exceptional high-quality polypropylene capacitors in the signal path were used
  • if a turntable is fitted with two tonearms, one having an MM phono cartridge installed and the other MC, both can be connected simultaneously without mutually affecting each other
  • high variability of gain settings, resistances and capacitances settings for all types of phono cartridges
  • a high-quality step-up Lundahl transformer for MC phono cartridges
  • SRP: 7.199,- €

Specifications
Load capacity MM / Gain 50, 150, 270, 370, 520, 620, 740, 840 pF / Gain: 46 dB
Input impedance MC1 / Gain 10, 20, 40, 80, 150, 300, 600, 1.200 Ω / Gain: 70 dB
Input impedance MC2 / Gain 2, 5, 10, 20, 40, 80, 150, 300 Ω / Gain: 76 dB
Output impedance < 250 Ω
Inputs XLR -> MC; RCA -> MM / MC
Outputs RCA / XLR
Total Harmonic Distortion MM / MC <0,1% / 1 VRMS
Subsonic filter / threshold frequency 18 dB / Octave / 18 Hz
RIAA accuracy 0,3 dB / 20 Hz - 20 kHz
Signal-to-noise ratio MM < 72 dBV (87 dBV - IEC - A)
Signal-to-noise ratio MC < 72 dBV (87 dBV - IEC - A)
Tube complement 8 x 6922EH, 1 x 6CA4EH
Tube complement 30 V / 50 Hz / 70 VA
Dimensions (w x h x d) 435 x 170 x 485 mm
Weight (net) 18 Kg
