CD 2.10

Tube DA converter/CD player

  •  a tube DA converter/CD player utilizing AK4490 32-bit DA converter
  • a silent slot-in CD drive mechanism
  • PCB`s utilize our premium CMT TM technology
  • analog signal is being processed by strictly symmetrical tube circuits
  • coaxial input separated by a high-frequency transformer
  • super symmetrical passive filters optimized for highest steepness



  • SRP 3.499,-€
Specifications
Frequency range: 20 Hz – 20 kHz (-0,3 dB)
Total harmonic distortion: <0,005 % (1 kHz)
Signal-to-noise ratio: >102 dB (20 Hz – 20 kHz)
Outputs: RCA / XLR
Analog output impedance: <200 Ohm
Analog output voltage unbalanced RCA: 2 Vrms
Analog output voltage balance XLR: 4 Vrms
Digital inputs: Coaxial, optical
USB – PCM 32 Bit/768 kHz
USB – DSD 64/128/256
other digital inputs: 24 Bit/ 192 kHz
Digital outputs: Coaxial, optical
Tube complement: 4 x 6922
Power: 230 V / 50 Hz / 60 VA
Dimensions (W x H x D): 435 x 120 x 405 mm
Weight (net): 12 kg
